- Can output 3 dimension laser lines at the same time
- Can form 6 cross lines
- 3 dimension laser lines can work separately
- Can work against wall in 8mm
- Alarming function can be turned off and machine can work in lean-state
- High power laser, brighter
- You can select touch mode and mechanical button mode
- The top cross is aligned with the ground cross, perpendicular to the ground
Single package size
63X33X30 cm
Single gross weight
5.300 kg
| Laser model | 3Dx360° |
| Wave length | 505-520nm |
| Working range | 10m-40m |
| Vertical Accuracy | ±1mm/5m |
| Horizonal Accuracy | ±1mm/5m |
| Horizonal Accuracy(90° vertical line) | 40" |
| Self-leveling time | <15s> |
| Out-of-level warning | ≥3° Laser lines flickering |
| Accuracy (micro-motion base | 360° |
| Self-leveling method | Automatic adjustment |
| Operating temperature | -10°C~+40°C |
